CP-Symbols Mechanical - Marks possesses basic marks that are used in mechanical industry drawings.

• joint symbols (left, right - without description, with description, with a closed description),
• weld views (e.g. V-joints, fillet welds),
• surface roughness (general symbols roughness, obtained by take layers of material, obtained without take layers of material).

Description

CP-Symbols program also contains general commands: Lines (pipes, ducts, cables) – this function allows to draw single-line lines in a schematic view. Frames and tables – contains a library of basic frames and drawing tables. Attributes and descriptions – is used to edit attribute values of one or many symbols. Bill of materials – is used to create specifications from elements used in the drawing. Languages: User interface supports 23 languages, i.e. English, Bulgarian, Chinese (Simplified), Croatian, Czech, Danish, Dutch, Finnish, French, German, Greek, Hungarian, Italian, Latvian, Polish, Portuguese, Romanian, Russian, Serbian, Slovenian, Spanish, Swedish and Turkish.
